Ready for 4th Generation Intel Core Processors (C6/C7 Idle Mode)
With price and performance in mind, the EVGA 500B is the best value power supply for your next build on a budget. With 80 Plus Bronze standard, over 80% efficiency under typical loads, the EVGA 500B is a great choice. Combining 500W of continuous power and Single +12V High AMP rail design, gain maximum power and efficiency while staying protected with a series of over volt/over current protections all bundled into one!
NOTE: For power supplies purchased in Europe, a European style power cable will be provided.
Learn more here
Cable Length
|
1x 550mm |
|
1x 600mm |
|
1x 550mm, 670mm |
|
2x 450mm, 570mm, 690mm |
|
1x 450mm, 570mm, 690mm (f) |
|
1x 120mm |
|
1x 1200mm |
|
No |
Connector Quantity
|
1x |
|
1x 8pin (4+4) |
|
2x 8pin (6+2) |
|
6x |
|
3x |
|
1x |
Power Specs
|
100 - 240 VAC, 8-4A, 50 - 60 Hz |
|
+3.3V |
+5V |
+12V |
+5Vsb |
-12V |
|
24A |
20A |
40A |
3A |
0.3A |
|
40A |
|
120W |
480W |
15W |
3.6W |
|
500W @ +40C |
Additional Details
|
0° to 40° C |
|
No |
|
No |
|
100,000 Hours |
|
4 lbs |
|
85mm (H) x 150mm (W) x 140mm (L) |
TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS
Compliance with ErP Lot 6 2013 Requirement
|
|
120mm
Sleeve Bearing |
Product Warranty
This product comes with a 3 year warranty. Registration is recommended.
Quiet and Intelligent Auto Fan for near-silent operation
80 PLUS Bronze certified, with 85% efficiency or higher under typical loads
Double Ball Bearing Fan
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Awards of the EVGA 500 B1, 80+ BRONZE 500W, 3 Year Warranty, Includes FREE Power On Self Tester Power Supply 100-B1-0500-KR (100-B1-0500-KR)
The EVGA 500B 500W Power Supply is a quality, affordable solution for anyone who's on a budget.
With the 500B, EVGA did pretty much what they set out to do - release a good, solid, no frills power supply at an affordable price.
The electrical performance of the power supply is very good, especially considering the price range of the product, it is efficient and has relatively low running temperatures.
We have a good quality bronze rated unit in the shape of the 500B. It offered decent electrical readings and efficiency well within spec while remaining quiet during our testing, where it powered our test components with ease. The real win for this unit though is the excellent retail price of just £40.
